High corrosive and oxidation resistance diaphragm pump:
We offer material of 316SS, Hast C, Teflon to promise safety and reliable in application.
According to real application, we offer it with flexibility for OEM and local site. Oil free, contamination free, no leakage.
The pump is the smallest pump offered providing exceptional quality, reliability and affordability.
Available 230V/460V voltage power supplier and 50HZ/60HZ Ex-proof motor.
Double diaphragm for low leakage reason.
Maximum performance range: 0-150L/min(0-9 m³/h), 0-28.5¡±Hg(965mbar), and 0-75 PSIG (4.83bar).
Available with Explosion proof UL (Class I, Div I group B, C, D), CSA, ATEX (EExd IIC T4 IP65), and Air Driven motor options.
Offer£º
24hours continual running
High sealing performance-no interference risk
High corrosiveness resistance and Oxidation resistance-to sure accuracy and safety
Strong bearing over expected
No maintenance, low noise
360 degree position installation
Medium temperature up to 205 degree Celsius
Offer 115V-60HZ/230V-50HZ/460V EX-proof motor power supplier
metallic pump head£¬no plastic Spiral crack risk
standard£º EX-Proof
|
Pump head material
|
316SS
|
aluminum£¨Teflon coating£©
|
Hast C
|
|
Diaphragm
|
Dupont Teflon coating/EPDM base/ All Teflon
|
|
Motor
|
AC motor
|
|
voltage
|
115V-60HZ(EX-Proof)
|
230V-50HZ(EX-Proof)
|
460V (EX-Proof)
|
|
Optional
|
Double diaphragm
|
Heated steam
|
|
